Code : U-507
Brand : Unitta
Accessories:
| Product name | Mike horizontal arm | Mike Long Arm | Electromagnetic sensor | Mike formula code |
|---|---|---|---|---|
| Part No. | TM-YOKO | TM-LONG1 | TM-DGS | TM-COM |
| RoHS Directive | Compliant | Non-conforming goods | Compliant | Compliant |
| Specification |  |
 |
 |
 |
| Because there is a microphone on the side, can be measured even in the narrow gap between the back of the belt and the machine | Microphone for standard (170 mm in length), part of the long arm type (350 mm in length) | Rather than sound waves, so that changes in the magnetic field sensed by the sensor, can be measured, such as steel wire and steel belt. In an environment susceptible to noise in the rubber belt, even if not measured in the normal microphone, can be measured is applied to thin magnetic material. | Microphone-in microphone is standard code expressions 1m length measurement of the belt at the back of the machine was hard that can be measured. |
※ You can also use U-505, U-305 the previous product.
